Melamine Formaldehyde Moulding Plastic is a thermosetting polymer widely used in electrical appliances, household goods, automotive parts, and woodworking products due to its excellent heat resistance, flame-retardant properties, electrical insulation, smooth surface, and ease of coloring.
This article summarizes the key processing factors that affect the quality of molding materials when bamboo powder is added, based on experimental research. By properly controlling these parameters, manufacturers can achieve melamine formaldehyde resin molding compounds with higher mechanical strength, better waterproofing, lower shrinkage, and better surface appearance.
Melamine formaldehyde moulding plastic(Melamine formaldehyde resin) is formed by the condensation of melamine and formaldehyde under the action of a catalyst. Cellulose, curing agent, release agent, etc., are added to the resin for kneading; the mixture is then dried, crushed, ball-milled, and screened to obtain molding powder. The molding powder can be formed by hot pressing.
By modifying cellulose, the mechanical strength and transparency of the product can be improved, while modifying the resin can reduce the product’s formaldehyde emissions. Through deep processing, its product series can reach or exceed the level of similar foreign products, and the production of multiple varieties of molded plastics can meet the increasing demand for high-end products in domestic and foreign markets, thereby achieving better economic benefits.
In recent years, using bamboo powder as a natural reinforcement filler has become a popular way to enhance performance while supporting renewable and low-cost materials
The performance of molding materials depends on several processing parameters:
The amount of bamboo powder directly affects the mechanical and processing properties.
The higher the content of bamboo powder, the higher the bending strength and impact strength
Excessive bamboo powder → reduced fluidity, making molding difficult.
Best bamboo powder ratio: 50%
When using 50% bamboo powder:
Good mechanical performance;
Suitable for stable flowability during molding;
Balancing Cost and Performance.
Drying can remove moisture and volatile components from resin bamboo mixtures. Improper drying can lead to defects such as bubbles, poor curing, and severe shrinkage.
The experiment used 70 ° C drying and compared different times:
Best drying time: 6 hours
Pretreatment of bamboo powder with sodium hydroxide can remove impurities such as pectin, lignin, and hemicellulose, thereby enhancing bonding between bamboo and microfiber resin.
The test results show that:
0% NaOH: Low bending strength
5% NaOH: moderate improvement
10% NaOH: maximum bending strength, good boiling water resistance, low mold shrinkage
15% NaOH: Overtreatment → Higher shrinkage rate and unstable performance
In practical processing, 10% NaOH has the highest flexural strength (68.36 MPa) (15% NaOH has 70.56 MPa, but higher shrinkage and surface foaming rates).
Boiling water resistance indicates that the surface will bubble at all treatment levels, but will not fade or wrinkle.
Best: 10% – the optimal balance between strength (68.36 MPa) and low mold shrinkage (0.63%).
Finer powders can achieve better diffusion, higher density, smoother surfaces, and higher strength.
60 grid: rough surface, low strength
80 Net: Better but not shiny
100 mesh: Smooth and glossy surface, highest bending strength, lowest shrinkage
Finer powder (100 mesh) significantly improved the flexural strength (77.36 MPa, an increase of 13.4% compared to 60 mesh) and reduced the mold shrinkage rate (0.71%).
As the fineness increases, the surface quality changes from rough to smooth.
Best: 100 mesh – provides the highest strength, lowest shrinkage rate, and an attractive glossy surface.
| Parameter | Optimal value | Effect on properties |
|---|---|---|
| Bamboo powder ratio | 50% | High flexural (66.87 MPa) & impact (1.75 kJ/m²) + good fluidity (132 mm) |
| Drying time (70°C) | 6 hours | Moisture 3.75%, volatiles 3.5%, mold shrinkage 0.83% – no blistering |
| NaOH concentration | 10% | Flexural strength 68.36 MPa, low shrinkage (0.63%), acceptable boiling water resistance |
| Molding powder fineness | 100 mesh | Max flexural strength (77.36 MPa), min shrinkage (0.71%), smooth glossy surface |
Following these parameters yields MF/bamboo molding materials with excellent flexural strength (~77 MPa), impact strength (~1.95 kJ/m²), low shrinkage (<0.9%), and a glossy, defect‑free surface.
The melamine formaldehyde molding compound reinforced with bamboo powder, after appropriate treatment, is an excellent choice for environmentally friendly, high-performance thermosetting products. By optimizing the bamboo powder content, drying time, alkaline pretreatment, and powder fineness, manufacturers can significantly improve mechanical properties, water resistance, dimensional stability, and appearance.
This green composite material has broad application potential in tableware, electrical components, automotive parts, and woodworking equipment.
